Corsair FRAME 4000D RS ARGB Black Tempered Glass Modular Mid Tower ATX PC Case

Corsair FRAME 4000D RS ARGB Black Tempered Glass Modular Mid Tower ATX PC Case
Corsair FRAME 4000D RS ARGB Mid Tower Case - Black
Corsair FRAME 4000D RS ARGB Modular Gaming Case w/ Glass Side, E-ATX, 3x ARGB Fans, InfiniRail Fan Mounting, USB-C, Asus BTF Compatible, Black
Corsair FRAME 4000D RS ARGB, Black, RGB Mid Tower, Tempered Glass, Reverse Connection, USB 3.2 Type-C, 3x RS ARGB Fans
Manufacturers Code: CC-9011296-WW
EAN: 840440487715



FRAME 4000D RS ARGB Modular Mid-Tower PC Gaming Case from Corsair



Build Your Way

The revolutionary FRAME Modular Case System redefines customisation. Want to upgrade the motherboard tray to billet aluminium? Want to replace your front I/O panel for more USB ports? Now you can. The 4000D Refresh RS isn't just a case - it's your canvas, offering near limitless options for upgrades and changes so you can dominate the battlefield with unparalleled customisation. The InfiniRail™ Fan Mounting System allows for an easier building process, while three RS120 ARGB performance fans ensure your system stays cool under heavy load.

Endless Modular Possibilities

InfiniRail Fan Mounting System



This steel multi-point mounting system provides unmatched flexibility for front and roof fan configurations. Easily slide the rail to mount fans up to 200mm (140mm in the roof) exactly where you need them, ensuring targeted airflow without limitations of fixed mounting points.

Dual 360mm Radiator Support



Boost your cooling with three dedicated mounting locations for 360mm radiators - front, roof, and side. You can mount up to 10x 120mm fans simultaneously, ensuring continuous cool air intake and efficient hot air exhaust.

Three RS120 ARGB Fans Included



Get in the Frame

No Visible Cables
Fully compatible with reverse-connector motherboards from Asus, MSI, and Gigabyte, allowing for unobstructed airflow and a super-clean build.

Sag-Free Graphics Card
Every CORSAIR FRAME 4000D includes a GPU Anti-sag Stabilisation Arm to keep your GPU steady, so you never have to worry about damaging your PCIe slot.

Cable Shroud
Keep unused and overly long cables out of sight with the cable shroud for a clean and organised interior.

Wide Cooling Flexibility

Dimensions
The FRAME 4000D has more than enough space to accommodate and cool your most ambitious build.



Fan Capacity
The FRAME 4000D has more than enough space to accommodate and cool your most ambitious build.



Radiator Capacity
The FRAME 4000D has more than enough space to accommodate and cool your most ambitious build.



Modern Front Panel I/O

Comprehensive Connectivity
Puts your connections within easy reach, including a USB 3.2 Gen 2 Type-C Port, 2x USB 3.2 Gen 1 Type-A ports, and a combination audio/microphone jack.

1 - Power Button
2 - Headphone/Mic Combo Jack
3 - 2x USB 3.2 Gen 1 Type-A Ports
4 - USB 3.2 Gen 2 Type-C Port



Core Chassis Specifications

Case Edition     FRAME 4000D RS ARGB
Case Form Factor     Mid Tower
Motherboard Form Factor

ATX
E-ATX
MicroATX
Mini-ITX

Back Connect Compatible     Yes

I/O, Bays & Expansion
Front/Side/Top Panel I/O

1 x Headphone/Mic Combo
1 x Power Button
1 x Reset Button
2 x USB 3.2 Gen1 Type-A
1 x USB 3.2 Gen2 Type-C

Drive Bays     2 x 3.5" / 4x 2.5" Internal
Standard Expansion Slots     7
Vertical Expansion Slots

Fans & Filters
Fan Bays

2 x 120mm
3 x 120mm / 2x 140mm / 2x 200mm
7 x 120mm / 5x 140mm

Fans Included     3 x 120mm w/ Addressable RGB LEDs
Fan Controller/Hub
Dust Filters

Bottom
Front
Side

Liquid Cooling Support
Front Radiator Compatibility     1 x 240/280/360mm
Top Radiator Compatibility     1 x 240/280/360mm
Bottom Radiator Compatibility
Rear Radiator Compatibility     1 x 120/140mm
Side Radiator Compatibility     1 x 240/280/360mm

Clearances
Max CPU Cooler Height     170 mm
Max GPU Card Length     370 mm
Cable Routing Space

Side Panels
Window/s     Yes
Window Configuration     1 x Main Side
Window Construction     Tempered Glass

LED Lighting Functionality
LED Lighting     No
LED Lighting Emitters
LED Lighting Colour
LED Lighting Support & Control

Power Supply Compatibility
PSU Included     No
PSU Wattage (If Included)
PSU 80+ Rating (If Included)
PSU Support     ATX
PSU Mounting Location
Max PSU Length     180 mm

Chassis Physical Specifications
Colour     Black
Chassis Construction Materials     Steel / Tempered Glass
Dimensions     239 x 486 x 487 (WxHxD mm)
Weight     8.2 kg (Approx)
Package Type     Retail
Model Number     CC-9011296-WW
GTIN     840440487715
