ASRock Intel B760M PRO RS s1700 Micro-ATX Motherboard

ASRock Intel B760M PRO RS s1700 Micro-ATX Motherboard
Asrock B760M PRO RS, Intel B760, 1700, Micro ATX, 4 DDR5, HDMI, DP, 2.5G LAN, PCIe5, RGB, 3x M.2
ASROCK B760M PRO RS, Intel B760, LGA1700, DDR5, SATA3, PCIe 5.0, 3x M.2, 2.5GbE, USB 3.2 Gen1, mATX
Manufacturers Code: B760M PRO RS
EAN: 4710483942723



B760 Pro RS D4 Intel s1700 Micro-ATX Motherboard from ASRock



Upgraded and Simplified

The Race Sport (RS) Edition now takes its impressive legacy to new heights with the latest upgrade to DDR5 memory, delivering even faster speeds and efficiency. This Micro-ATX version maintains its sleek, modern aesthetic while packing powerful specifications into a more compact form factor. Built to support Intel 14th, 13th, and 12th Gen Core processors, it ensures smooth performance with PCIe 5.0 capabilities and two Hyper M.2 Gen4 slots for ultra-fast data transfers. With ASRock Polychrome Sync, you can create custom RGB lighting, and the upgraded Dragon 2.5G Ethernet keeps your networking fast and reliable. Perfect for enthusiasts craving performance, style, and space efficiency.

Intel B760Chipset
LGA 1700 Intel Socket
14th/13th/12th Gen Intel Core Processors
Micro-ATX Form Factor

Peak Power Precision

Game-Ready VRM
The 7+1+1 VRM layout is designed to deliver highly stable and efficient power directly to the CPU, offering smoother and more consistent performance. This multi-phase power design ensures that your processor receives a steady line of current, allowing you to load games quickly and reliably.

Dr. Mos Power Staging
Compared to conventional discrete MOSFETs, Dr. Mos delivers more current per phase, resulting in improved thermal efficiency. This makes it perfect for high-performance titles, focusing controlled and stable power delivery to components.

Multi-Layer PCB
The 6-layer PCB design further enhances signal stability and energy efficiency, helping to maintain lower temperatures even under demanding conditions. This, in turn, allows for greater memory overclocking potential, making it possible to support the latest high-performance memory modules without issue.

Unrivalled DDR5 Performance



XMP & EXPO Support
With support for Intel XMP and AMD EXPO profiles, simply enable the pre-tested settings for hassle-free performance gains. Just plug in compatible memory, apply the profile, and enjoy affordable, easy, and reliable overclocking

Protection Circuit
ASRock have equipped this board with a built-in protection circuit. This safeguard significantly reduces the chances of memory damage, ensuring that your hardware remains secure during upgrades or maintenance.

PCI Power

Ultra-Fast Storage
Equipped with PCIe 4.0 and multiple Hyper M.2 Gen4 slots, this motherboard ensures your storage is not just fast, but future-proof. Expect seamless performance no matter the workload.

Loaded with M.2 Slots
This setup supports PCI Express 4.0 M.2 SSDs, delivering data transfer speeds that are twice as fast as the previous generation. Experience the thrill of lightning-fast data transfers and elevate your gaming performance to new heights.



Steel PCIe Armour
The reinforced steel slot takes durability to the next level, confidently supporting the PCI Express 5.0 standard. Extra anchor points, a stronger latch, signal stability secure your cards like never before.



Super-Fast SMT
The SMT type PCIe slot is here to revolutionise your gaming experience. It turbocharges signal flow and maximises stability at lightning speed. With a mind-blowing bandwidth of 128GBps, you’re ready to unleash the full potential of future high-end graphics cards.

Polychrome RGB Sync

Full grasp on lighting and effects.
This motherboard features onboard RGB headers and an addressable RGB header that allows the motherboard to be connected to compatible LED devices such as strips, CPU fans, coolers, chassis and so on. Users may also synchronise RGB LED devices across Polychrome RGB Sync to provide a unique light show that spreads throughout the system.

Loaded with Features

Auto Driver Installer
Prepacked with an Ethernet driver, ADI can automatically download and install all necessary drivers.

Dragon .5Gb/s LAN
Dragon 2.5Gb/s LAN platform is built for the demanding requirements of home networking, content creators, gamers and streaming.

Front USB 3.2 Gen2 Type-C
The Front USB 3.2 Gen2 Type-C header delivers up to 10 Gbps data transfer rate, providing the front of your PC with a next generation reversible USB design.

NAHIMIC AUDIO
Whether you are using headphones, external or internal speakers, via USB, Wi-Fi, analogue output or even HDMI, Nahimic Audio offers you the most engaging listening experience.

Unlimited Connections

This motherboard is primed and ready to go, featuring a robust I/O layout for all your connectivity needs.



Specifications

Edition     B760M PRO RS
Form Factor     MicroATX
CPU Socket     1700
Chipset     Intel B760

RAM Memory Support
Memory Type     DDR5
Memory Channel     Dual (2)
Memory Type (ECC)     Non-ECC
Memory Type (R/U)     UDIMM (Unbuffered)
Memory Speed (Mhz)     DDR5 - 7200(OC)
Max. Memory Capacity     192GB

Audio
Audio     7.1 Channel HD Audio

Graphics Support
Primary GPU Interface     PCIe 5.0 (x16)
NVIDIA SLI Support     N/A
AMD CrossFire Support     N/A
Integrated Graphics     Requires Processor Graphics or Discrete GPU
On-Board Graphics Connectors

DisplayPort 1.4 (DSC)
HDMI 2.1

Internal Connectivity
Expansion Slots

1 x M.2 Key E
1 x M.2 Key E (Supports Wi-Fi modules)
1 x M.2, 22-42/60/80, PCIe Gen4x4
2 x M.2, 22-80, PCIe Gen4x4
1 x PCIe 3.0 x16 (x4 Bandwidth)
1 x PCIe 5.0 x16
4 x SATA 6GB/s

SATA Support     SATA3
RAID Support via
Storage Mode Support

RAID 0 (SATA only)
RAID 1 (SATA only)
RAID 10 (SATA only)
RAID 5 (SATA only)

Internal I/O

1 x 24-pin (Power)
1 x 4-pin CPU Fan Connector
1 x 8-pin (Power)
3 x Addressable Digital RGB Header
1 x Chassis Intrusion/Speaker Header
4 x Chassis Water Pump/Fan Connector
1 x CPU Water Pump/Fan Connector
1 x Front Panel Audio Header
1 x Front Panel USB Type-C Header
1 x RGB LED connector
1 x Thunderbolt AIC Connector (5-pin)
1 x TPM (SPI_TPM) header
2 x USB 2.0 Header
1 x USB 3.2 Gen1 Header
1 x USB 3.2 Gen2 Type-C Front Panel Header

External Connectivity
Network Interface Type     Wired 2.5 Gigabit LAN (10/100/1000/2500)
Network Chip/Modules     1 x Dragon RTL8125BG (2.5GbE LAN)
Rear I/O Connectors

2 x Antenna Ports
1 x DisplayPort 1.4
1 x Front Speaker Out
1 x HDMI 2.1
1 x Line In
1 x Mic-In
1 x PS/2 Keyboard/Mouse Combo
1 x RJ-45
2 x USB 2.0
3 x USB 3.2 Gen1 Type-A
1 x USB 3.2 Gen1 Type-C
1 x USB 3.2 Gen2 Type-A

Additional Specifications
Water Cooled     No
Cooling     Passive Heatsinks
QPI Speed     N/A
Board Dimensions     244 x 244 mm
Model Number     90-MXBLH0-A0UAYZ
GTIN     4710483942723
